Pre-treatment & Utility
Water Softener System
Automatic ion-exchange softeners that eliminate scale in boilers, chillers and process lines.
- Capacity
- 0.5 – 200 T/H
- Outlet Quality
- Total hardness ≤ 0.03 mmol/L
Hard water deposits calcium and magnesium scale on boiler tubes, heat exchangers, RO membranes and nozzles, wasting energy and shortening equipment life. An ion-exchange softener replaces the hardness ions with sodium, removing scaling potential completely.
Our softeners use a multi-port automatic control valve (time, volume or hardness triggered) with high-quality strong acid cation resin in FRP or stainless steel vessels. Single, twin-alternating and multi-tank configurations provide continuous soft water 24 hours a day.
Regeneration is fully automatic with an integrated brine tank and salt level alarm; downflow and upflow counter-current regeneration are both available for lower salt consumption.
Key Features
Why This System Performs
Continuous soft water
Twin-tank alternating operation keeps soft water available during regeneration of the other vessel.
Energy saving
Scale-free heat transfer surfaces recover 15 %–30 % of boiler fuel wasted by scale build-up.
Low salt consumption
Counter-current regeneration option cuts salt use significantly compared to downflow.
Long resin life
Food-grade strong acid cation resin with correct backwash expansion lasts 5–8 years.
Process
Typical Process Flow
- 01Raw water inlet + pre-filter
- 02Automatic multi-port control valve
- 03Strong acid cation resin bed (service)
- 04Backwash
- 05Brine draw and slow rinse (regeneration)
- 06Fast rinse
- 07Brine refill
- 08Return to service — soft water outlet
Specifications
Technical Data
| Capacity | 0.5 – 200 T/H |
|---|---|
| Outlet hardness | ≤ 0.03 mmol/L |
| Resin | 001 × 7 strong acid cation, food grade |
| Vessel | FRP, carbon steel lined or SUS304 |
| Control valve | Time / volume / hardness triggered automatic |
| Regenerant | Industrial salt, brine tank included |
| Working pressure | 0.2 – 0.6 MPa |
