Pre-treatment & Utility
Chemical Dosing Device
Integrated dosing skids for antiscalant, coagulant, pH adjustment, disinfection and boiler chemicals.
- Capacity
- 0.5 – 2,000 L/H per pump
- Outlet Quality
- Dosing accuracy ± 1 %, automatic pH / ORP linkage
A chemical dosing device delivers precisely metered chemical solutions into a water stream. Typical duties include antiscalant and reducing agent before RO, PAC / PAM coagulant before clarification, acid or alkali for pH correction, sodium hypochlorite for disinfection, and oxygen scavenger for boilers.
Each skid integrates a PE or stainless solution tank, an agitator, metering pump(s), pulsation damper, back-pressure and safety relief valves, calibration column and pressure gauge on a compact base plate.
Dosing rate can be set manually, driven proportionally by a flow signal, or closed-loop controlled by an online pH / ORP / residual chlorine analyser.
Key Features
Why This System Performs
Accurate metering
Diaphragm or plunger metering pumps with calibration column give ± 1 % dosing accuracy.
Closed-loop control
pH, ORP or residual chlorine analysers feed back to the pump for automatic dose correction.
Corrosion resistant
PE / PP / PVDF wetted parts and PE tanks handle acid, alkali, hypochlorite and polymer solutions.
Compact skid
Tank, agitator, pump, valves and instruments pre-piped and pre-wired for quick installation.
Process
Typical Configuration
- 01Chemical solution tank (100 – 5,000 L, PE / PP / SUS)
- 02Electric agitator
- 03Suction strainer + foot valve
- 04Metering pump (single or duplex)
- 05Calibration column
- 06Pulsation damper + back-pressure valve
- 07Safety relief valve + pressure gauge
- 08Injection quill into main pipeline
Specifications
Technical Data
| Dosing flow | 0.5 – 2,000 L/H per pump |
|---|---|
| Discharge pressure | 0.3 – 1.6 MPa (higher on request) |
| Tank volume | 100 / 200 / 500 / 1,000 / 2,000 / 5,000 L |
| Wetted material | PP / PVDF / PVC / SUS316L |
| Control mode | Manual, 4–20 mA proportional, or pH / ORP closed loop |
| Chemicals | Antiscalant, PAC, PAM, HCl, NaOH, NaClO, scavenger |
