Water Filling & Bottling Machine
Rinsing–filling–capping monoblocks and barrel filling lines for bottled and packaged water.
- Capacity
- 500 – 20,000 BPH
- Outlet Quality
- Hygienic filling, filling accuracy ± 1 %
Our filling machines complete the packaged water production chain: after purification, the 3-in-1 monoblock rinses, fills and caps PET bottles in one continuous rotary motion under a stainless steel hygienic enclosure.
Filling is by gravity or isobaric valve with accurate liquid level control, servo capping torque control and automatic bottle-missing / cap-missing rejection. Format change between bottle sizes is quick with change parts.
For 5-gallon barrel water, we supply semi-automatic and automatic lines including barrel decapping, brush washing, inside-outside rinsing, filling, capping and shrink-sleeve labelling.
Key Features
Why This System Performs
3-in-1 monoblock
Rinsing, filling and capping combined in a single rotary machine for a compact hygienic line.
Accurate filling
Gravity / isobaric valves with level control keep filling accuracy within ± 1 %.
Servo capping
Controlled capping torque prevents both leaking and over-tight caps, with auto rejection of faults.
Full line integration
Can be supplied with blow moulder, conveyor, labeller, date coder, film wrapper and palletiser.
Process
Typical Line Configuration
- 01Purified water supply from RO plant
- 02Bottle blowing / bottle infeed air conveyor
- 03Rinsing station
- 04Filling station
- 05Capping station
- 06Date coding
- 07Labelling
- 08Film shrink wrapping
- 09Palletising and warehouse
Specifications
Technical Data
| Output | 500 – 20,000 bottles per hour |
|---|---|
| Bottle size | 200 mL – 2 L PET, 5 gallon barrel line available |
| Filling accuracy | ± 1 % |
| Contact material | SUS304 / SUS316L |
| Control | PLC + touch screen, servo capping |
| Options | Blow moulder, labeller, coder, wrapper, palletiser |
