Wastewater & Water Reuse
Laboratory Wastewater Treatment Equipment
Compact cabinets that neutralise, oxidise and detoxify laboratory effluent before discharge.
- Capacity
- 50 – 2,000 L/day
- Outlet Quality
- pH 6–9, heavy metals and COD within sewer discharge limits
Laboratory wastewater is small in volume but complex and hazardous: strong acids and alkalis, heavy metal ions, organic solvents, reagents and biological residues. Discharging it untreated damages drainage systems and violates environmental regulations.
Our laboratory wastewater treatment cabinets collect effluent from sinks and fume hoods, then automatically run a sequence of pH neutralisation, redox reaction, heavy metal chelation and precipitation, filtration, activated carbon adsorption and photocatalytic oxidation before discharge.
The unit is fully enclosed with odour control, operates automatically with a touch screen, and records treatment batches for environmental inspection.
Key Features
Why This System Performs
All-in-one cabinet
Collection, reaction, filtration and adsorption integrated in one enclosed stainless cabinet.
Automatic batch treatment
Level-triggered batch cycles with automatic dosing and pH control, no operator intervention required.
Heavy metal chelation
Specialised chelating agents capture Cu, Pb, Cd, Cr and Hg to below sewer limits.
Traceable records
Batch logs of pH, dosing and discharge time support environmental compliance audits.
Process
Typical Process Flow
- 01Laboratory drain collection tank
- 02Pre-filtration / solid separation
- 03pH neutralisation reactor
- 04Redox and chelation dosing
- 05Flocculation and precipitation
- 06Multi-media filtration
- 07Activated carbon adsorption
- 08Photocatalytic / UV oxidation
- 09Compliant discharge with batch record
Specifications
Technical Data
| Treatment capacity | 50 – 2,000 L/day |
|---|---|
| Discharge pH | 6 – 9 automatic control |
| COD removal | 70 % – 90 % |
| Heavy metals | Chelation to sewer discharge standard |
| Cabinet | SUS304 enclosed, odour controlled |
| Control | PLC + touch screen, batch logging |
