Wastewater & Water Reuse
Wastewater Treatment Equipment
Integrated physical, chemical and biological treatment plants for industrial and domestic effluent.
- Capacity
- 5 – 5,000 m³/day
- Outlet Quality
- GB 18918 Grade 1A or local discharge standard
Our wastewater treatment equipment covers the full chain — screening and equalisation, coagulation and air flotation, biological treatment (A/O, A²/O, MBBR or MBR), sedimentation, advanced oxidation, filtration and disinfection — supplied either as a civil-works plant or as a fully integrated buried / containerised unit.
The process is selected after analysing your effluent: COD, BOD, ammonia nitrogen, total phosphorus, suspended solids, oil and specific toxic components. We then simulate the treatment train and guarantee the required discharge quality.
Integrated MBR units are particularly popular for factories, hospitals, hotels, schools and residential compounds where footprint is limited and the effluent will be reused.
Key Features
Why This System Performs
Process to suit the effluent
A/O, A²/O, MBBR, MBR, air flotation and advanced oxidation combined to fit your specific pollutant load.
Stable compliance
Designed with margin so discharge stays within limits despite load and temperature fluctuation.
Buried / containerised options
Integrated units can be buried under landscaping or shipped as a plug-and-play container.
Low sludge, low odour
Optimised sludge age and closed structures with deodorisation reduce sludge output and nuisance.
Process
Typical Process Flow
- 01Coarse and fine screening
- 02Equalisation / regulating tank
- 03Coagulation + dissolved air flotation
- 04Anaerobic / anoxic tank
- 05Aerobic tank (MBBR or activated sludge)
- 06MBR membrane tank or secondary clarifier
- 07Advanced oxidation / activated carbon
- 08Disinfection (NaClO or UV)
- 09Discharge or reclaimed water reuse
- 10Sludge thickening + dewatering
Specifications
Technical Data
| Capacity | 5 – 5,000 m³/day (larger by project) |
|---|---|
| COD removal | ≥ 90 % |
| Ammonia nitrogen | ≤ 5 mg/L |
| SS | ≤ 10 mg/L |
| Discharge standard | GB 18918 Grade 1A / local limits |
| Structure | Carbon steel anti-corrosion, SUS304 or FRP |
| Control | PLC automatic with remote monitoring |
Applications
